A new generation, quality upgrading LED UV Flatbed Printer MT-1212R is dexterous, highly active, energy saving, industrial grade machine!
The new LED UV Flatbed Printer MT-1212R is a compact UV flatbed printer. It is smaller in size than the other flatbed printer models in our range, which is ideal for printing companies who have limited space. As you would expect, MT-1212R is very strong and extremely well engineered that adopts the best quality imported components.
1. Ricoh Gen5 Top Class Printhead
The MT-1212R LED UV Flatbed Printer adopts Ricoh Gen5 Top Class high speed Printhead. It contains 1280 nozzles of each printhead that is more than three times nozzle of Ricoh Gen4 printhead!
2. New Variable Size Droplet Technology
The New Variable Droplet Control Technology achieves stunning and seamless gradation that to make the printing more delicate and accurate. There are more detailed and smoother gradient printouts can be achieved by this technology. It means the printing quality is greatly enhanced and accelerates the printing speed too. Therefore, more and more efficient print jobs can be accomplished and thus enhance the productivity!
3. Energy Saving and Environmental Protection
The most unique feature of MT-1212R is the LED UV Lamp that can be started and stopped at anytime without preheating but time saving. Otherwise, there is no pollution, no odor and curing immediately without faded after the LED UV Light Curing the LED UV Ink!
4. The Ink Detection Alarm System
When any color ink will run out of ink barrel, this system can point out which color you should add extra ink immediately.
5. Color Options
The LED UV Flatbed Printer MT-1212R can be configured as C M Y K/C M Y K Lc Lm/C M Y K C M Y K and C M Y K W V. Moreover, this UV printing machine can print white color as bed, cover or spot color.
6. High Power of Servomotor
MT-1212R adopts high power servomotor cooperate with digital accurate driver which can be achieved LED UV Flatbed Printer running accuracy!
7. High Quality UV LED Lamp
We equipped with high quality famous brand UV LED Curing Lamp for our LED UV Flatbed Printer MT-1212R. There is non-deformation and non-cracking after printing, but rapid drying and long lifetime!
8. Media Positioning Pin
There is a unique Media Positioning Pin and one-button Pneumatic Controller installed in this LED UV Flatbed Printer MT-1212R! It provides accuracy and convenience respectively for panel loading and panel positioning. This function also avoids any deviation of repetitive printing.
Industries Application of MT UV Flatbed Printer
UV Flatbed Printer can be use for various industries, such as building decoration industry, glass industry, mark and sign industry, exhibition industry, rigid paperboard packing industry, leather, art-ware industry, furniture industry etc.
And for more applications, the UV printing materials could be: glass, ceramic, ceiling, aluminum sheet, wood board, door sheet, metal panel, billboard, acrylic panel, Plexiglass, paper board, foam board, PVC expansion board, corrugated cardboard, flexible materials such as PVC, canvas, cloth, carpet, reflective film, leather, Aluminum Panels, Wall Panel, PVC Panels, Organic Board, Ceramics, Chevron Board, Metal Board, fiber board, Plastic, Brick, Stone, Home and Office Decoration, Electric Appliances Shell, Wall Decoration, Furniture, Tile, Gift, 3C Product, Oil Painting And Fresco, Sliding Door And Wood Door, Wedding Photography and all kinds sheet materials and coiled materials, etc.
1. It is required to keep machine workshop clean without dust.
2. It is required to equip air conditioner and humidifier for machine working room, to keep temperature between 20 ℃ and 28 ℃, moisture between 40% and 60%.
3. It is required every day to check the input power of machine, to ensure stable single phase AC 220V power.
4. It is required to use cleaning flush to clean printhead nozzles every day, in order to keep printhead in good condition
In China even the whole world, MT Digital Industry Co., Ltd. is one of the best UV printer manufacturer. We have owned international brands "MT" and "Refretonic", MT manufactory is directly located in Shanghai, so MT manufactory can get the best supporting equipment for MT UV printer, thus the MT UV printer can ensure the superior quality, so the performance ratio is very high.
MT Digital Industry Co., Ltd. is one of the best leading manufacturer, supplier and exporter of UV printing machine in China. We produce different UV printer series (UV Flatbed Printer, Hybrid UV Printer and Roll to Roll UV Printer), thus we supply the UV Printer to decoration industry, advertising industry, signage industry, glass industry, acrylic industry, wood industry, ceramics industry, MDF industry, leather industry, corrugated cardboard industry, wallpaper industry, and plexiglass industry. We are complying with European standards and we always import main parts from overseas. MT UV printing machines have gained CE certificate. They are exported to many countries and regions.
1. Maximum monthly production volume is 50 sets for UV Printers.
2. MT payment term for machine order is only T/T 50% as deposit, and 50% paid before shipping.
Packing and Transportation
1. Packing: Inner packed by anti-rust & water-proof plastic bubble film, outer packed by solid wooden crate.
2. Transportation: MT manufactory is located in Shanghai city, nearby the Shanghai port, and MT company enjoys convenient transportation.
1) Advantage by air cargo, maritime shipping, express delivery.
2) The shipping cost is in customer's account.
3) For domestic customers we will deliver machine within 12 to 20 working days after we receive customer's order.
|Mode Type||Ricoh UV Flatbe Printer MT-1212R|
|Printhead||Micro Piezoelectric Ricoh Gen5 printheads 7PL|
|Max. printing Size||1200 * 1200mm|
|Max. Media Thickness||Up to 80mm|
|Printing speed||Standard Output Mode: 45sqm/hr, Production Mode: 30sqm/hr, High Precision Output Mode: 15sqm/hr, Ultra-high quality output mode: 8sqm/hr|
|Printing Resolution||600dpi, 900dpi, 1200dpi, 1800dpi|
|Technology||Piezoelectric Inkjet, UV-curable inkjet, grayscale printing|
|Color Configuration||4 Colors / Double 4 Colors / 6 Colors / White Color & Varnish Is Optional|
|drying system||LED UV Curing lamp|
|Ink type||LED UV curing ink (3 years outdoor and 10 years indoor)|
|Ink reservoir capacity||2.5 liter ink drums automatic ink control with non-stop filling ink function|
|ink supply system||automatic negative ink supply system|
|control system||windows 2000 workstation / windows xP / vista / windiw 7, 32bit, RAM≥6G|
|RIP software||Photoprint/ colorgate|
|Color management||ICC based color management|
|File formats||TIFF, JPEG, Postscript, EPS, PDF, etc...|
|Media handling||Flatbed Sheet Feeding, Vacuum Platform Supports Various Rigid Materials. Automatic Media pneumatic positioning system Is Used For Easy Loading And Accurate Printing and Unique opposite blowing switch Function Makes Media Unloading Easier (optional). |
|Printing media||Glass, acrylic, ceramic tile, aluminum, Iphone case, plastic, Foam board, wallpaper, wall art, sign advertising, metal, paper, wood, MDF, furniture, card, Marble, golf products, gift & promotion products, leather, PU, PMMA, PVC, PP, PE, PTFE, Plexiglass, Panels, Ceiling, Organic Board, Corrugated, Chevron Board, Fiberboard, Brick, Stone, Home & Office Decoration, Electric Appliances panel, Pottery & Porcelain Tile, 3C Product, Oil Painting, Fresco, Sliding Door, Wedding Photography, Mark And Signs, Exhibition, Etc......|
|air draft||2 air draft divisions adapt to the max. dimension of printing area|
|Rigid Material size||Standard vacuum table support rigid materials up to 1300 * 1680mm, 100kg/sqm|
|Roll-feed media size||None|
|Data interface||High speed USB transmission|
|UV energysource||Dual shuttered LED UV lamps, independent user-selectable control of shutter aperture and two lamps power levels|
|printer Dimensions||L2700 * W2000 * H1500mm|
|package dimensions||L2800 * W2100 * H1600mm|
|working Temperature||18 to 26℃ (between this temperature is more effectively control satic and guarantee printed quality)|
|Relative humidty||40%-70%, non-condensing (minimum 40% recommended for synthetic media to avoid static electricity, maximum 70% recommended for paper-based media to avoid buckling)|
|power supply||max. power Input voltage: 200 to 240VAC, signal-phase, 50/60Hz, 15A max|
