Product Introduction And Specification


MT1700F2 is a new double-side hot and cold laminator for signage and Graphic industries that is manufactured by MT Industry. Up to 1620mm(64'') lamination width, mounting up to 28mm(1.1'') and the temperature up to 120°C (248°F) for both rollers. Hot and cold laminator MT1700F2 is a laminator for producing extremely demanding requirement. It use with cold or thermal films for single-side or double-side lamination that max speed is 9m/min. This wide format and heavy duty laminator is designed for widest choice of surface laminating possibilities. MT1700F2 will enable you to produce the most demanding product quality with highly efficiency.

All of MT Industry full auto double-side hot laminators have a wide range of application. The capable of 8 meter per minute lamination use cold or hot laminating films with low or high heating. MT1700F2 is the ideal commercial laminating solution. Heat-assist for cold adhesive film is the best performance during cold laminating and mounting. Precise air pressure and nip-gap control offer better and easy operation experience. Standardized emergency buttons and laser eye ensures the operator works in complete safety.


  • Double Side Hot Laminator MT-1700F2

1. MT Industry Laminator MT1700F2 equipped with Anti oblique feeding system, which can laminate whole roll material within one time, avoids skewed picture, greatly improve coating efficiency and reduce labor costs! Front work platform equipped with anti-pinch cover and printing material rail guider, which is humane design. 90w adjustable deceleration torque system controls both 130mm diameter of imported anti-high-temperature silicone upper roller and 130mm diameter of anti-sticking silicone under roller.

2. MT Laminator MT1700F2 also equipped with unilateral linkage manual liftable silicon rubber roller, upper roller lifts up and down by a hand wheel operate, which is simple operation for synchronous lifting and automatic pressure equalization.

3. MT Industry Laminator MT1700F2 adopts automatic material collection system for laminated film. The advantages are convenient, save labor, less working space, and improve the yield.

4. The laminating tension system is adjustable setting, which can be adjusted through the feeding system and auto-backing paper takes off device. It can improve the film ductility and effectively prevent wrinkles.

5. Roller equipped with self-locking mandrel that provides easy loading for both sides of your film roll. Once laminated, the finished products can pivot onto the take-up roll. Round edge of thick pivoting feed tray avoids damage printing image during lamination.

  • Double Side Hot Laminator MT-1700F2

6. MT Industry Laminator MT1700F2 adopts front and back aluminum alloy work platform, scratch resistance, long life, reduce the cost and improve quality. Otherwise, foldable front work platform to facilitate machine maintenance and repair also can save working space.

7. MT Industry Laminator MT1700F2 provides high efficiency laminating and high yield that directly reduces the cost of 30 cents per square meter.

8. MT Industry Laminator MT1700F2 can be used for low heating cold laminating. 50℃ cold laminating makes better color reproduction, high brightly and completely avoid bubbles and snowflake spots.

9. MT Industry Laminator MT1700F2 achieves the 50 meters whole roll material laminating or longer without oblique.

10. Hot laminating can achieve 240m/h by single staff or unmanned operation.

11. Low heating cold laminating can achieve 420m/h by single staff or unmanned operation.

12. MT Industry Laminator MT1700F2 adopts patented film roller feeding system brings you a new experience of lamination. The thin adhesive material will not wrinkle and dark picture also laminating fastness.

  • Double Side Hot Laminator MT-1700F2

13. MT Industry Laminator MT1700F2 adopts auto backing paper takes off device and laminated film collecting system.

14. MT Industry Laminator MT1700F2 has wide range of applications such as indoor printing, outdoor printing, car stickers, graphic, poster and so on.

15. MT Industry Laminator MT1700F2 adopts fully adjustable nip-gap and pressure function, simple film tension adjustment function, light weight drop-in shafts with auto grip easy loading function, roll-to-roll operation function and foot switch for pieces accurate lamination.

16. There is a spare film releasing roller under the Laminating machine, easy disassembly, easy to replace and save time to reset film roller.

17. MT Industry Laminator MT1700F2 equipped with a foot switch for hands free operation, two emergency stops, optical eyes and non-contact infrared temperature control system. Otherwise, CE certificate is available.

Product Specification


Mode TypeDouble Side Hot Laminator MT-1700F2
Max. Lamination Width1630mm/64''
Max. Lamination lengthunlimit
Max. Lamination Thickness28mm/1.1''
Max Temperature150℃/302。F
String poleYes
Up And DownAir Pressure
Warm up time15-20mins
Power Consumption0.9-1.8kw/h
Heated methodInfrared
Power Input4300W
Net Weight260kg
