Product Introduction And Specification


MT- 1805DEW Water Base Printer is 2018 Deluxe Version of high precision Micro Piezo Printer which with 1.8m printing width, high-resolution printing  indoor large format printer. The printing quality is competitive to the Japanese Water Base Printer brands like,Epson Water Base Printer, Roland printer, Mimaki Water Base Printer and Mutoh Water Base Printer. 1440dpi overturns the highest resolution of traditional solvent printers, which leads the resolution of large format printing to a new standard. Your new profit pattern will be established and new business opportunity will be discovered.


  • Piezo Water based Printer

1. This Water Base Printer equipped with two Dx5 printhead (two Ricoh Gen5 printheads are optional), Standard printing with double heads to meet the demand of high resolution and faster speed.

2. This water base printing Machine through different quality tests is stable and competent enough for mass production requirement.

3. This Water Base Printer equipped with intelligent infrared heater and fan drying system.

4. The LED UV printing system is optional; you may upgrade this Water Base Printer to a LED roll-to-roll UV Printer once demanded.

5. This Water Base Printer adopts Aluminum-Alloy girder, which is the most strongest and smoother than other metal materials, ensuring you high precision printing quality.

6. As a top quality Water Base Printer, MT- 1805DEW adopts THK 20mm width linear guide rails with double-slider and sound off function, more durable and reliable for high precision printing.

  • Piezo Water based Printer

7. This Water Base Printer owns strong heavy-duty machine body (double stands and feet composite without any shake) ensures stable printing for long time work.

8. We provide automatic feeding and collecting structure to this Water Base Printer, especially adopts all-aluminum dual power take up system to carry the whole weight of media more stably and easily media feed in and take up. Professional soft film collecting and feeding system is optional too.

9. Media sensor for test media when media is going to running out.

10. Anti-collision performance was also equipped on this Water Base Printer. When the sensor installed on the both sides of the carriage detect the position of the printhead is lower than the thick medium, the carriage will initiate an immediate stop to protect the printheads.

11. Automatic capping system is easy operation and maintenance for our Water Base Printer.

12. Bulk ink supply system is standard option for our Water Base Printer, which is setting on top, easy to monitor ink level and easy ink refill.

  • Piezo Water based Printer

13. Our Water Base Printer adopts USB 2.0 interface control system that get better large data transfer and anti-signal interference. Otherwise, it is also supporting windows7/64bit.

14. This Water Base Printer adopts metal optical cable from mainboard to carriage board, to make sure fast and stable data transit.

15. This Water Base Printer equipped with two original Leadshine Motor Control, which provide more stable quality and better efficiency.

16. This Water Base Printer adopts six or more variable droplet printing technology; the highest printing resolution is up to 2880dpi.

17. This Water Base Printer also adopts VSDT variable droplet technology, the smallest droplet can reach as 1.5pl, but the maximum is 27pl, which presenting perfect printing quality.

18. As the top quality Water Base Printer in China, we also adopt widened 65mm Roller System instead of 40mm roller, which is 25mm wider than normal roller. This 65mm Roller System can provide excellent control of media feeding, ensuring high precision of large format printing.

Product Specification


Mode TypeWater based Printer MT-1805DEW
PrintheadTwo DX5 Drop-on-demand Micro-Piezo Printheads
Number of Nozzles2880 Nozzles (2 Heads)
Color4 Colors:Cyan, Magenta, Yellow, Black
Resolution1440dpi (max.)/1440dpi
Height of Print Head2-5mm
Size of Ink Droplet1.5-21 pl
Max. Printing Width1800mm(74'')
Max. Media Width1900mm (Max.)/1900mm
Real Time TrackingNone
Printing Speed3pass44.0sq.m per hour
4pass32.0sq.m per hour
6pass22.0sq.m per hour
8pass16.0sq.m per hour
12pass11.0sq.m per hour
Media FeederYes
Media Take-upYes
MaterialMax. Weight70kg
Application TypeHigh Glossy Photopaper,Self Adhesive High Glossy Photopaper,Self Adhesive PP Paper(Semi-Glossy),Self Adhesive PP Paper(Matt),Self Adhesive PP Paper(High-Glossy),PP Paper (Glossy/Matt),PET Flim For Glass Decoration,Reverse Printing Bcaklit PET Film,Front Printing Backlit Film,Transparent Self Adhesive PVC,White Glossy Self Adhesive PVC,Inkjet Rigid PVC Film,Cold Lamination Film,Cross Lamination Film,Ground Cover Lamination Film
InkTypeWater Based Ink
Ink Tank Reservoir Capacity4 * 1.5 Liter bulk continuous ink supply
Auto cleanning systemAuto cleanning system with anti clogged flash spray & moisturizing function
Picture drying systemfan drying system, infrared heating
Media AdsorptionMulti-section Intelligent Suction System With Adjustable Strength
InterfaceHigh Speed USB Transmission USB2.0/3.0
PowerPower VoltageAC220-240V 50-60HZ, AC110-120V 50-60HZ (optional)
Control SoftwarePrint Console
RIP SoftwareMaintop (Photoprint Wasatch Optional)
Three heating sectionsPre-heater, printing bed heater, rear heater
Operation SystemMS Windows XP, Windows 7
Printing EnvironmentTemperature 18-32 Degrees,  Humidity 46-65 Rh
Picture TypeJPG PSD TIFF
Printer DimensionW3200 * D900 * H1350mm
Packing DimensionW3330 * D1020 * H760mm
Net Weight298kg
Gross Weight448kg
